FEATURES (U-8)

• Xmax = 18mm one-way by 70% BL
• RMS Power = 750-watts
• Vented magnetic gap featuring 12 chamfered gap vents
• Vented pole-piece with chamfered edges
• High velocity under-spider frame vents
• Black Aluminum 2.25 voice coil former for superior heat dissipation
• High Temperature copper voice coil wire
• Large Magnet ID aluminum faraday ring
• Spring Loaded Terminals
• Stitched-On XL Tinsel Leads to prevent fatigue and failure
• High strength & patented cast aluminum frame
• Optimized for small, ported enclosures
• Bolt-Through Motor Design for enhanced longevity

SPECIFICATIONS
