Specifications

• NUMBER OF CHANNELS : 1 CH
• MAX OUTPUT POWER : 14.4VDC – 1 OHM :1750W RMS
• INPUT SENSITIVITY : 200MV
• SIGNAL TO NOISE RATIO 108 DB
• FREQUENCY RESPONSE: 10HZ 20KHZ (-3DB)
• CROSSOVER :
• HPF: 10 TO 1KHZ (-12DB/8) VARIABLE
• LPF: 40HZ TO 20KHZ (-12DB/8) VARIABLE
• BASS BOOST : 0 TO 12DB (50HZ)
• THERMAL MANAGMENT ; SMART COOLER ( FAN POWERED BY TEMPERATURE OR AUDIO, WITH 3 SPEEDS)
• INPUT IMPEDANCE: 56K OHMS
• PROTECTION SYSTEM ; OUTPUT SHORT / HIGH /LOW SUPPLY VOLTAGE / THERMAL PROTECTION
• MINIMUM SUPPLY VOLTAGE : 9VDC
• MAXIUM SUPPLY VOLTAGE : 16VDC
