FEATURES

• Full Range Digital 4 Channel Amplifier
• Double Sided Through Hole Epoxy PCB
• Multi-Way Protection Circuitry ( Thermal / Voltage / Speaker Short / DC Offset )
• Voltage, Temperature, and Clipping Display Wired Remote Control (Optional / Not Included with Multi-Channels)
• Clipping indicator on amplifier side-panel
• Optimized for standard 12v charging systems (Low Voltage Technology)

SPECIFICATIONS

• Input Sensitivity : 6V – 0.2V
• 1400 x 2 @ 4 ohms RMS
• 700 x 4 @ 2 ohms RMS
• 500 x 4 @ 4 ohms RMS
• 2 OHM Stereo Stable / 4 OHM Bridged Stable
• Variable Subsonic Crossover Filter : 10HZ – 500HZ
• Variable High Pass Filter : 50HZ – 500HZ ( 500HZ – 5KHZ at x10 )
• Variable Low Pass Filter : 50HZ – 500HZ ( 500Hz – 5KHZ at x10 )
• X1, X10 Crossover Multiply
• Efficiency : 75% 4OHM, at 100HZ
• Signal / Noise Ratio : 105DB <
• Damping Factor : 400 <
• Frequency Response : 10 Hz 25khz
• 12DB/ OCT Variable Crossover Slope (HPF/LPF)
• 12DB/ OCT Variable Subsonic Crossover Slope
• Tested Voltage & THD : 12.8V & Less Than 1% THD
• Operation Voltage : DC 9V – 15.5V Power Input
• Recommended Fuse : 300 Amps
• Dimensions : 14.96 L x 6.85 W x 2.66 H
