FEATURES

• Digital Class-D Linkable Mono Block Amplifier
• Dual MOS-FET PWM Power Supply
• 1 Ohm Stable Load
• 24 dB/Octave Variable Low Pass Filter
• 24 dB/Octave Variable Subsonic Filter
• 9 dB/Octave Variable Bass Boost
• 180 Variable Phase Shift
• 4 Way Protection Ciruit (Thermal, Voltage, Speaker Short, DC Offset)
• Wired Remote Control with Voltage & Temperature Display and Clipping Indicator

SPECIFICATIONS

• Input Sensitivity : 6V – 0.2V
• 4000 x 1 @ 2 ohms RMS Linked
• 2000 x 1 @ 1 ohms RMS Mono
• 1000 x 1 @ 2 ohms RMS Mono
• 500 x 1 @ 4 ohms RMS Mono
• Variable Subsonic Crossover Filter : 10HZ – 50HZ
• Variable Low Pass Filter : 35HZ – 250HZ
• Bass Boost @ 45Hz 0-9dB
• Efficiency : 90% <
• Signal / Noise Ratio : 90DB <
• Damping Factor : 400 <
• Frequency Response : 10 Hz 250 HZ
• Phase Shift Control 0-180 Degrees
• Tested Voltage & THD : 12.8V & Less Than 1% THD
• Operation Voltage : DC 9V – 15.5V Power Input
• Recommended Fuse : 200 Amps
• Dimensions : 15.74 L x 8.67 W x 2.80 H
