FEATURES

• High Fidelity Class A/B Multi-Channel Design
• 12dB/Octave-Variable Subsonic Filter
• 12dB/Octave-Variable High Pass Filter
• 12dB/Octave-Variable Low Pass Filter
• Clipping Indicator
• 4 Way Protection Circuit (Thermal,
• Voltage Speaker short and DC Offset)
• Optional Wired Remote Control with Clipping Indicator

SPECIFICATIONS

• Input Sensitivity 6V Max
• 125 x 4 @ 2 ohms RMS
• 100 x 4 @ 4 ohms RMS
• Variable High Pass Filter : 40HZ – 5kHZ
• -12dB/8 Variable Crossover Slope (LPF/HPF)
• Signal / Noise Ratio : 92DB
• Operation Voltage : DC 10.5V – 15.5V Power Input
• Dimensions : 14.88 L x 6.3 W x 2.75 H
