Nominal Impedance

8 ohms

AES Power Handling

160W

Program Power Handling

320W

Peak Power handling

640W

Sensitivity (1w/1m) With Horn

114dB

Frequency Response

630Hz-20KHz

Recommended Hi Pass Crossover

900Hz

Sold in Pair or Single

Single

Voice Coil Diameter

2 / 51.5mm

Voice Coil Former Material

Kapton

Winding Material LITTIE

CCA

Diaphragm Material

Titanium

Magnet Material

Ferrite

Magnet Weight

35 Oz

Body Material

Aluminum

Nominal Diameter

6.5 / 165mm

Throat Diameter

2 / 50.8mm

Sound Coverage

57 Rounded

Body Material

Aluminum

Color/Finish

Black / Satin

Overall Diameter

6.14 / 165mm

Overall Depth

6 / 50.8mm

Mounting Depth

5.8 Rounded

Mounting Hole Diameter

5.7 / 145mm

Bolt Pattern (Horn)

6.33 / 161mm x 4 0.21 / 5.5mm Hole
