Rated Continuous (RMS) Power @ 14.4 V
| @ 4 |
75 W RMS x 4 |
| @ 3 |
100 W RMS x 4 |
| Bridged @ 4 |
200 W RMS x 2 |
Rated Continuous (RMS) Power @ 12.5 V
| @ 4 |
60 W RMS x 4 |
| @ 3 |
90 W RMS x 4 |
| Bridged @ 4 |
180 W RMS x 2 |
General Specifications
| Frequency Response |
12 Hz – 22 kHz (+0, -1dB) |
| S/N Ratio, referred to highest rated power |
>104 dB below rated power (A-weighted, 20 Hz – 20 kHz noise bandwidth) |
| S/N Ratio, referred to 1 W |
>84 dB (A-weighted, 20 Hz – 20 kHz noise bandwidth) |
| Damping Factor @ 4 |
>150 / 50 Hz |
| Damping Factor @ 2 |
>75 / 50 Hz |
| THD+N @ Rated Power |
<1% @ 2 per Ch. |
| Input Voltage Range @ RCA Inputs |
Switchable from 200 mV – 2 V RMS (Low) to 800 mV – 8 V RMS (High) |
| Min.Copper Power / Ground Wire Gauge |
4 AWG wire |
| Fuse Rating |
40 A (AFS, AGU or MaxiFuse) |
Signal Processing
| Filter Mode(s) |
Low-Pass or High-Pass |
| Filter Slope(s) |
12 dB/octave |
| Filter Frequency Range |
50 Hz – 500 Hz |
| Detented, Calibrated Filter Freq. Potentiometers |
No |
| Filter Defeat Function |
Yes |
| Remote Level Control |
No |
| Remote Level Modes |
N/A |
| Channel Input Mode Switch |
Yes (2/4 ch.) |
| Pass-Through Preamp Output |
Buffered |
| Source Channel Selection for PreOuts |
No |
Physical Specifications
Height (H) 2.13 in / 54 mm Width (W) 9.78 in / 372 mm Depth (D) 6.96 in / 177 mm
