Rated Continuous (RMS) Power @ 14.4 V
| @ 4 |
75 W RMS x 4 |
| @ 2 |
100 W RMS x 4 |
| Bridged @ 4 |
200 W RMS x 2 |
General Specifications
| Frequency Response |
20 Hz – 20 kHz (+0, -1dB) |
| S/N Ratio, referred to highest rated power |
>93 dB below rated power (A-weighted, 20 Hz – 20 kHz noise bandwidth) |
| S/N Ratio, referred to 1 W |
>76 dB (A-weighted, 20 Hz – 20 kHz noise bandwidth) |
| Damping Factor @ 4 |
>60 / 50 Hz |
| Damping Factor @ 2 |
>30 / 50 Hz |
| THD+N @ Rated Power |
<1% @ 2 per Ch. |
| Input Voltage Range @ RCA Inputs |
200 mV – 4 V RMS |
| Input Voltage Range @ High-Level Inputs |
2 V – 10 V RMS |
| Min.Copper Power / Ground Wire Gauge |
4 AWG wire |
| Fuse Rating |
40 A (AFS, AGU or MaxiFuse) |
Signal Processing
| Filter Mode(s) |
Low-Pass or High-Pass |
| Filter Slope(s) |
12 dB/octave |
| Filter Frequency Range |
50 Hz – 200 Hz |
| Detented, Calibrated Filter Freq. Potentiometers |
No |
| Filter Defeat Function |
Yes |
| Remote Level Control |
No |
| Remote Level Modes |
N/A |
| Channel Input Mode Switch |
Yes (2/4 ch.) |
| Pass-Through Preamp Output |
Unbuffered |
| Source Channel Selection for PreOuts |
No (always 2 Ch) |
Physical Specifications
| Height (H) |
2.10 in / 53 mm |
| Width (W) |
9.50 in / 242 mm |
| Depth (D) |
7.5 in / 190 mm |
