| Nominal Diameter |
10 |
| Nominal Impedance |
4 Ohms |
| RMS Power handling |
300W |
| MAX Power Handling |
900W |
| Sensitivity (1w/1m) |
98dB |
| Frequency Response |
45Hz – 22KHz |
| Recommended HI Pass Crossover |
55Hz |
| BODY / FEATURES |
|
| Enclosure Material |
Injection PC + ABS |
| Marine Grade Type |
IP65 + UV Stable |
| RGB LED Lighting |
Integrated LED-RGB Speaker Lighting,
Integrated LED-RGB Acrylic Ring Lighting,
and with 6 Core Wires for Lighting and Speaker |
| Grill Type |
ABS + 316 Stainless Metal Mesh |
| Single or Pair |
Pair |
| Clamps |
Die-Cast Adjustable (1″~2″)
360 Degree Rotation Mounting, Buried Wire or Open Wire
Mounting Optional, Included NBR Pad And Stainless
Hardware (Screws, Stop Washers, Hexagon wrench, |
| Front Logo |
Yes, Can be Rotated for Correct Angle Display |
| Rear Logo |
Radiator Fixed Position |
| WOOFER SPECIFICATIONS |
|
| Voice Coil Diameter |
2″ |
| Cone Material |
Waterproof Compress Paper |
| Surround Material |
Soft PC Damping Glued |
| Basket Materia |
PC Injection Molded Composite |
| Magnet Material |
Neodymium |
| Magnet Grade |
N40H |
| Passive Radiator |
6.1 with LED RGB Light |
| TWEETER SPECIFICATIONS |
|
| Voice Coil Diameter |
1.75″ |
| Type |
Bullet |
| Diaphragm Material |
Titanium |
| Magnet Material |
Neodymium |
| Crossover |
6dB/Oct |
| THIELE & SMALL PARAMETERS |
|
| Equivalent Volume |
29.74L |
| Excursion (one way) |
6 mm |
| Free Air Resonance |
55 Hz |
| Total Factor |
0.621 |
