AudioControls Original Digital Bass Restoration Circuit:Restore missing low notes and transform flat audio into rich, powerful bass you can truly feel.
ParaBASS Controls for Bass Shaping:Precisely sculpt and fine-tune your bass to perfectly match your music, vehicle, and personal preference.
Selectable PFM Subsonic Filter with Bypass:Protect your speakers and ensure tighter, more controlled bass by filtering out inaudible, power-wasting frequencies.
Built-in Line Driver for Optimal Output Voltage:Boosts your audio signal for a strong, clean path to your amplifiers, minimizing noise and maximizing sound quality.
Balanced Line Level Inputs:Helps eliminate electrical interference and hum, delivering crystal-clear sound even in noisy car environments.
Speaker-Level Inputs:Seamlessly integrate a factory stereo without needing RCA outputs, saving money and simplifying upgrades.
Load Selection Switch:Ensures perfect compatibility with modern factory stereos, preventing issues and guaranteeing a smooth upgrade.
GTO and Audio Sense Turn On:Automatically powers up the unit when your stereo is active, making installation simpler and operation seamless.
10 Volt Maximum Output Level:Sends a strong, clean signal to your amplifier, unleashing maximum power and dynamic impact.
Conformally Coated PCB:A protective layer against moisture, dust, and temperature swings, improving the durability and reliability of The Epicenter Micro PRO.
ACR-4 Dual-Knob Remote Level Control Included:Command your bass instantly from the driver’s seat, fine-tuning levels and bass restoration on the fly.
SPECIFICATIONS
INPUTS
- Maximum Line Level Input: 10Vrms
- Maximum Speaker Level Input: 40V / 400W (20k setting)
- Line Level Input Impedance: 7k
- Speaker Level Input Impedance (selectable): 20, 60, 20k
OUTPUTS
- Maximum Output Level (THD<1%): 9Vrms, 13V peak
- Output Impedance: 150
PERFORMANCE
- Total Harmonic Distortion: 0.03%
- Signal to Noise: >105 dB
- Frequency Response: 10 Hz 22 kHz 1 dB
- PFM Filter (High Pass): Selectable 24 Hz, 15 Hz, or Bypass
CONTROL
- Remote In / GTO Signal Sense / Audio Sense
- 12VDC Remote Out (always active when unit is on)
GENERAL
- Power Supply: High Headroom PWM Switching
- Current Draw: 300 mA
- Recommended Fuse Rating: 1 A
WEIGHTS & DIMENSIONS
- Dimensions: 8L x 3D x 1H
- Weight: 0.9 lbs
